Ethernet Interface

• 10/100BaseT(X) Ports (RJ45 connector): 2 Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection
• 100BaseFX Ports (multi-mode SC connector): 2
• Optical Fiber: 1
• Optical Fiber: 100BaseFX
• Optical Fiber: Multi-Mode
• Optical Fiber: Single-Mode
• Optical Fiber: Fiber Cable Type
• Optical Fiber: OM1
• Optical Fiber: 50/125 µm
• Optical Fiber: G.652
• Optical Fiber: 800 MHz x km
• Optical Fiber: Typical Distance
• Optical Fiber: 4 km
• Optical Fiber: 5 km
• Optical Fiber: 40 km
• Optical Fiber: Wavelength
• Optical Fiber: Typical (nm)
• Optical Fiber: 1300
• Optical Fiber: 1310
• Optical Fiber: TX Range (nm)
• Optical Fiber: 1260 to 1360
• Optical Fiber: 1280 to 1340
• Optical Fiber: RX Range (nm)
• Optical Fiber: 1100 to 1600
• Optical Fiber: 1100 to 1600
• Optical Fiber: Optical Power
• Optical Fiber: TX Range (dBm)
• Optical Fiber: -10 to -20
• Optical Fiber: 0 to -5
• Optical Fiber: RX Range (dBm)
• Optical Fiber: -3 to -32
• Optical Fiber: -3 to -34
• Optical Fiber: Link Budget (dB)
• Optical Fiber: 12
• Optical Fiber: 29
• Optical Fiber: Dispersion Penalty (dB)
• Optical Fiber: 3
• Optical Fiber: 1
• Optical Fiber: Note: When connecting a single-mode fiber transceiver, we recommend using an attenuator to prevent damage caused by excessive optical power.Note: Compute the “typical distance” of a specific fiber transceiver as follows: Link budget (dB) > dispersion penalty (dB) + total link loss (dB).

Power Parameters

• Power Consumption: 1.56 W (max.)

Physical Characteristics

• IP Rating: IP30
• Dimensions: 29.7 x 144.4 x 144.8 mm (1.17 x 5.69 x 5.7 in)
• Weight: 230 g (0.51 lb)

Environmental Limits

• Operating Temperature: -40 to 75°C (-40 to 167°F)
• Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
• Ambient Relative Humidity: 5 to 95% (non-condensing)

MTBF

• Time: 740,661 hrs
• Standards: Telcordia (Bellcore), GB

Warranty

• Warranty Period: 5 years
• Details: See www.moxa.com/warranty
