Armv7 Cortex-A8 1000 MHz processor
Dual auto-sensing 10/100 Mbps Ethernet ports
SD slot for storage expansion
Programmable LEDs and a programmable button for easy installation and maintenance
Cybersecurity functions
Debian 9 open platform
Long-term Linux support until 2027; includes bug fixes and security patches

Computer

• CPU: Armv7 Cortex-A8 1 GHz
• DRAM: 512 MB DDR3
• Pre-installed OS: Linux Debian 9 (kernel v4.4)
• Storage Pre-installed: 8 GB eMMC
• Supported OS: Moxa Industrial Linux 1 (Debian 9, kernel 4.4), 2027 EOLSee www.moxa.com/MIL

Computer Interface

• USB 2.0: USB 2.0 hosts x 1, type-A connectors
• Expansion Slots: mPCIe slot x 1
• Number of SIMs: 1
• SIM Format: Mini
• Buttons: Reset button
• Ethernet Ports: Auto-sensing 10/100 Mbps ports (RJ45 connector) x 2
• Serial Ports: RS-232/422/485 ports x 2, software selectable (RJ45)

Ethernet Interface

• Ethernet Ports: Auto-sensing 10/100 Mbps ports (RJ45 connector) x 2
• Magnetic Isolation Protection: 1.5 kV (built-in)

LED Indicators

• System: Power x 1 SD slots x 1 Programmable x 4
• Wireless Signal Strength: Cellular/Wi-Fi x 3

Serial Interface

• Serial Ports: 2 x RS-232/422/485
• Console Port: 1 x 4-pin header to DB9 console port
• Data Bits: 5, 6, 7, 8
• Parity: None, Even, Odd, Space, Mark
• Stop Bits: 1, 1.5, 2
• Baudrate: 300 bps to 921.6 kbps
• Flow Control: RTS/CTS, XON/XOFF ADDC (automatic data direction control) for RS-485 RTS Toggle (RS-232 only)

Serial Signals

• RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
• RS-422: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-2w: Data+, Data-, GND
• RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND

Power Parameters

• Input Voltage: 12 to 36 VDC
• Input Current: 500 mA @ 12 VAC
• Power Consumption: 6 W

Reliability

• Alert Tools: External RTC (real-time clock)
• Automatic Reboot Trigger: External WDT (watchdog timer)

Physical Characteristics

• Housing: Metal
• Dimensions: 141 x 125.6 x 54.8 mm (5.55 x 4.94 x 2.15 in)
• Weight: 550 g (1.22 lb)
• Installation: DIN-rail mounting Wall mounting (with optional kit)

Environmental Limits

• Operating Temperature: -40 to 85°C (-40 to 185°F)
• Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
• Ambient Relative Humidity: 5 to 95% (non-condensing)
• Vibration: 2 Grms @ IEC 60068-2-64, random wave, 5-500 Hz, 1 hr per axis (without USB devices attached)
• Shock: IEC 60068-2-27

Standards and Certifications

• Safety: UL 60950-1
• EMC: EN 55032/35
• EMI: CISPR 32, FCC Part 15B Class A
• EMS: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV IEC 61000-4-5 Surge: Power: 1 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMF
• Green Product: RoHS, CRoHS, WEEE
• Hazardous Locations: Class I Division 2

MTBF

• Time: 535,916 hrs
• Standards: Telcordia (Bellcore) Standard

Warranty

• Warranty Period: 5 years
• Details: See www.moxa.com/warranty

Available Models

Model No.	Description	Quantity
UC-8112-ME-T-LX	Arm-based wireless-enabled DIN-rail industrial computer with 1 GHz CPU, 512 MB RAM, 2 Ethernet ports, 2 serial ports, 1 Mini PCIe slot, -40 to 85°C operating temperature
UC-8112-ME-T-LX1	Arm-based wireless-enabled DIN-rail industrial computer with 1 GHz CPU, 1 GB RAM, 2 Ethernet ports, 2 serial ports, 1 Mini PCIe slot, -40 to 85°C operating temperature
