ANT-WDB-ONM-0707 SERIES
07 dBi at 2.4 GHz and 07 dBi at 5 GHz, N-type (male), dual-band omnidirectional antenna
High-gain antenna to enhance performance
Waterproof N-type connector
Lightweight
Housing provides IP65 protection
-40 to 85°C operating temperature range
Waterproof N-type connector
Lightweight
Housing provides IP65 protection
-40 to 85°C operating temperature range
Antenna Characteristics
- Frequency: 2.4 to 2.4835 GHz or 5.15 to 5.85 GHz
- Antenna Type: Omni-directional
- Typical Antenna Gain: 7/7 dBi
- Impedance: 50 ohms
- HPBW/Horizontal: 360°
- V.S.W.R.: 1:2.5 max.
- Power Handling: 10 W (max.)
- Polarization: Vertical
- Connector: N-type (male)
Physical Characteristics
- IP Rating: IP65
- Dimensions: Diameter: 20 mm (0.79 in) Length: 528 mm (20.79 in)
- Weight: 152 g (0.34 lb)
- Radome Color: White
- Radome Material: Fiberglass
- Installation: Straight mount
Environmental Limits
- Operating Temperature: -40 to 85°C (-40 to 185°F)
- Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
Warranty
- Warranty Period: 1 year
- Details: See www.moxa.com/warranty
