ANT-WDB-ARM-0202 SERIES
2 dBi at 2.4 GHz or 2 dBi at 5 GHz, RP-SMA (male), dual-band, omnidirectional antenna
Small size for easy installation
Lightweight for portable deployment
Tilt and swivel design
Flexible installation
RP-SMA-type (male) connector
Lightweight for portable deployment
Tilt and swivel design
Flexible installation
RP-SMA-type (male) connector
Antenna Characteristics
- Frequency: 2.4 to 2.5, 4.9 to 5.825 GHz
- Antenna Type: Omni-directional
- Typical Antenna Gain: 2/2 dBi
- Connector: RP-SMA (male)
- Impedance: 50 ohms
- Polarization: Linear
- HPBW/Horizontal: 360°
- V.S.W.R.: 2:1 max.
- Power Handling: 1 W (max.)
Physical Characteristics
- Weight: 9.65 g (0.02 lb)
- Length: 136 mm (5.35 in)
- Radome Color: Black
- Radome Material: Plastic
- Installation: Straight mount
Environmental Limits
- Operating Temperature: -40 to 75°C (-40 to 167°F)
- Storage Temperature (package included): -40 to 75°C (-40 to 167°F)
- Ambient Relative Humidity: 5 to 95% (30°C, non-condensing)
Warranty
- Warranty Period: 1 year
- Details: See www.moxa.com/warranty
