MDR POWER SUPPLY SERIES
DIN-rail 24 VDC power supply with 40W/1.7A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature
The MDR series of power supplies provides a reliable DC power source for any industrial control system. Combining wide operating tempeature range (-20~70°C), compact enclosures, industrial standards and approvals, and offering short circuit, over load, over voltage, and over temperature protection, the MDR series makes your power supply choice a simple one.
The MDR series has passed a 100% full load burn-in test, and are UL/CUL listed, TÜV/CB certified, and CE marked. Models are available with output ratings from 40W to 60W, with 24 VDC output. Customers can choose from a full range of input voltages (85 to 264 VAC) making the MDR series unbeatable.
Benefits
- Economical and reliable DC power source for industrial devices
- -20 to 70°C operating temperature range
- Design for use in harsh industrial environment
Applications
- Factory automation
- Transportation automation
- Utility automation
- Building automation
| Power | 60 W |
| Input | 85-264 VAC (47-63 Hz) or 120-370 VDC |
| Output | 60 W, 24 VDC, 0-2.5 A |
| Over-voltage Protection | 31.2-36 V |
| Overload Protection | 105-150 % |
| Type | Constant Current Limiting |
| Reset | Auto Recovery |
| Inrush Current | 30 A and 115 V, or 60 A and 230 V |
| Safety Standards | TÜV EN60950-1, UL508 Approved |
| EMC Standards | CISPR22 (EN55022) Class B, EN61000-4-2/3/4/5/6/8/11, ENV50204, EN61000-3-2, EN50082-2 |
| Dimensions | 40 x 90 x 100 mm |
| Weight | 280 g |
| Operating Temperature | -20 to 70°C (-4 to 158°F) |
| Relative Humidity | 20 to 90% RH |
| Warranty | 3 years |
