ABC-02 SERIES
Configuration backup and restoration tool, firmware upgrade, and log file storage tool for managed Ethernet switches and routers, 0 to 60°C operating temperature
One-click backup and auto-load technology to reduce system downtime
Powerful troubleshooting tool to record mass event logs
Supports Moxa’s managed Ethernet switches and wireless APs/bridges/clients
Auto-backup of switch configuration files when any setting is changed
Plug-and-Play system configuration backup and restoration
Powerful troubleshooting tool to record mass event logs
Supports Moxa’s managed Ethernet switches and wireless APs/bridges/clients
Auto-backup of switch configuration files when any setting is changed
Plug-and-Play system configuration backup and restoration
Interface
- Connector: USB 2.0 Type A
Basic Operation
- Storage Capacity: 1GB SLC type NAND Flash
Power Parameters
- Input Voltage: 5 VDC (through USB interface)
Physical Characteristics
- Housing: PVC molding
- IP Rating: IP40
- Dimensions: 32.5 x 97 x 12 mm (1.28 x 3.82 x 0.47 in)
- Weight: 50 g (0.11 lb)
- Installation: M4 screws (
Environmental Limits
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Storage Temperature (package included): -40 to 85°C (-40 to 185°F)
- Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
- EMC: EN 55032 Class A
- EMI: CISPR 32, FCC Part 15B Class A
- EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
Warranty
- Warranty Period: 5 years
- Details: See www.moxa.com/warranty
